Radar anticollisione IP66 79 GHz, FMCW, connessione Wi-Fi, area rilevamento 0.3~6 m (regolabile), area anticollisione 0~2 m (regolabile), target rilevabili: persone e veicoli, 1 porta RS485, 2 ingressi (1 per update) e 1 uscita (relè), alimentazione 9~12 Vdc <3 W
| Basic | |
| Emission Frequency | 77 GHz–81 GHz |
| Emission Power | ≤ 10 mW Vertical: ± 10°, horizontal: ± 36° |
| Response Time | 50 ms |
| Detection Region | 0.3 m–6 m (0.98 ft–19.69 ft) (adjustable) |
| Anti-smashing Region | 0 m–2 m (0 ft–6.56 ft) (adjustable) |
| Function | |
| Detection Target | Human, vehicle Yes, through serial port or mobile app (with Wi-Fi |
| Online Commissioning | connection) Yes, through serial port or mobile app (with Wi-Fi |
| Update | connection) |
| Port | |
| RS-485 | 1 |
| I/O | 2 (1 for update input, 1 for relay output) |
| General | |
| Operating voltage | 9 V–12 V DC |
| Operating Current | < 0.25 A |
| Power Consumption | < 3 W |
| Operating Temperature | –40 °C to +85 °C (–40 °F to +185 °F) |
| Protection Grade | IP66 96 mm × 60 mm × 16.4 mm (3.78" × 2.36" × 0.65") |
| Product Dimensions | (L × W × H) |
| Net Weight | 70 g ± 10 g (0.15 lb ± 0.02 lb) |
| Gross Weight | 220 g ± 20 g (0.49 lb ± 0.04 lb) |
| Installation | Case side mount |
| Ordering Information | |
| Type | Model Description |
| Anti-smashing | 79 GHz distribution-specific anti- DHI-ITSJC-2303-DC12 |
| radar | smashing radar |
