Embedded Video Storage IP single controller, massima banda 800 Mbps, fino a 320 canali IP, predisposto per montaggio di 16 dischi (fino a 18 TB cad.), Hot-swap, RAID 0/1/5/6/10/50/60, 2 porte LAN 1000 Mbps, 2 porte USB 3.0, 1 porta eSATA, 1 porta RS232, 1 porta HDMI/VGA (debug), 3U, alimentazione ridondante 100~240 Vac <220 W
Datasheet
Manuali
| System | |
| Main Processor | 64-bit high-performance multi-core processor |
| Operating System | Embedded Linux OS Web (PCAPP) |
| Operating Interface | Single controller |
| Controller | 8 GB by default (extendable to 32 GB) |
| Cache | Face detection, face recognition, IVS (abandoned object, missing object, loitering, crowd gathering, parking, fence-crossing, fast moving, tripwire and intrusion), video metadata (human, vehicle, non-motor vehicle), vehicle recognition, people counting (fisheye or people |
| AI by Camera | counting camera required),face & body detection, crowd distribution, smart thermal (call detection, visible channel- smoking detection, thermal channel- smoking detection) Works with camera for fire alarm, temperature alarm, |
| Thermal | |
| People Counting | regional people counting and queue people counting Works with camera for manual tracking, auto tracking, |
| Bullet-PTZ Smart Track | click positioning and select positioning |
| Fisheye Dewarp | Supports dewarping for fisheye cameras |
| Cluster | N+M |
| Third-party Camera | Onvif, Onvifs, RTSP, Sony, Panasonic, Axis, Arecont, |
| Access | Pelco, Canon, Samsung, Hikvision |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Audio Compression | G.711A; G.711U; PCM; G726 |
| Network | |
| Network Protocol | DHCP; DNS; DDNS; P2P; GAT1400; iSCSI; FTP ; SMB ; NFS |
| Mobile Phone Access | DMSS |
| Interoperability | ONVIF (Profile S); CGI; SDK |
| Browser | Chrome; PCAPP; IE9 or higher; Firefox NIC binding mode such as multiple-address mode, load |
| Network Mode | balance, fault-tolerance, etc |
| Multi-channel Playback | Max. 16-channel playback Auto record; manual record; search video detection; IO |
| Record Mode | alarm; thermal imaging; intelligent event; all record file |
| Storage Method | Internal HDD and network disk |
| Backup Method | HDD, peripheral USB storage device |
| Playback Function | 2. Full-screen, backup (clip; file), snapshot, digital zoom, audio on; off |
| Storage | |
| Video Direct Storage | Recording: 320-channel (bandwidth: 800 Mbps) |
| (Private Protocol) | Outgoing: 320-channel (bandwidth: 800 Mbps) Playback: 32-channel (bandwidth: 64 Mbps) Incoming: 320-channel (bandwidth: 800 Mbps) |
| Video Direct Storage | Recording: 320-channel (bandwidth: 800 Mbps) |
| (Onvif) | Outgoing: 320-channel (bandwidth: 800 Mbps) Playback: 32-channel (bandwidth: 64 Mbps) Incoming: 320-channel (bandwidth: 800 Mbps) |
| Video Direct Storage (Auto | Recording: 320-channel (bandwidth: 800 Mbps) |
| Register) | Outgoing: 320-channel (bandwidth: 800 Mbps) Playback: 32-channel (bandwidth: 64 Mbps) Incoming: 320-channel (bandwidth: 800 Mbps) |
| Video Direct Storage | Recording: 320-channel (bandwidth: 800 Mbps) |
| (International Protocol) | Outgoing: 320-channel (bandwidth: 800 Mbps) Playback: 32-channel (bandwidth: 64 Mbps) Incoming: 120-channel (550 KB/picture) Recording: 120-channel (550 KB/picture) |
| Picture Direct Storage | Outgoing: 120-channel (550 KB/picture) Playback: 32-channel (550 KB/picture) |
| Disk Group | Yes |
| iSCSI | Supports client and Server |
| Network Disk | Supports client RAID 0/1/5/6/10/50/60; |
| RAID | (with enterprise-grade HDD) Supports record control (continuous, event-based, |
| Record Management | scheduled, scheduled & event-based). |
| Storage Pool | Yes 280-channel × 2 Mbps video stream writing and 24-channel × 2 Mbps video playback (I/O size of VMS is 64 KB) |
| IPSAN Performance | 400-channel × 2 Mbps video stream writing and 24-channel × 2 Mbps video playback (I/O size of VMS is 512 KB) |
| Alarm | |
| General Alarm | Motion detect; tampering; IPC external alarm IPC offline alarm; storage error; HDD full; video frame loss; SSD exception; IP conflict; MAC conflict; login lock; fan malfunction; no HDD; network security exception; |
| Anomaly Alarm | power exception; disk health exception; RAID exception; storage pool exception; temperature alarm; share service Record; snapshot (full image); alarm uploading; remote device alarm output; camera audio; buzzer; log; preset; email, smart tracking |
| Alarm Linkage | and warning light. Disarming alarm linkage action by period or one-click sync disarm config with channels |
| Port | |
| HDD Interface | hot swapping CMR support enterprise-grade HDD |
| eSATA | 1 port |
| RS-232 | 1 port, for debug or COM data transmission |
| USB | 2 ports. 2 USB3.0 ports at the rear panel |
| HDMI | 1 port, only for debug |
| VGA | 1 port, only for debug 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports. |
| Network Port | (gigabit electrica port) |
| Power | |
| Network Port Extension | 2 × 10-GbE optical fiber ports (optional) |
| General | |
| Power Supply | 100-240 VAC 50-60 Hz, 6.3A-3.5A <60 W (without HDD, idling) |
| Power Consumption | <220 W (all HDDs connected) |
| Fan | Intelligent speed regulation fan |
| Net Weight | 15.5 kg (34.17 lb) |
| Gross Weight | 17.2 kg (37.92 lb) Chassis: 484.6 mm × 133.2 mm × 473.6 mm (19.08" × |
| Product Dimensions | 5.24" × 18.65") (W × L × H) With packaging: 589mm × 619 mm × 290 mm (23.19" × 24.37" × 11.42") (W × L × H) |
| Packaging Dimensions | Protection box: 605 mm × 635 mm × 312 mm (23.82" × 25.00" × 12.28") (W × L × H) |
| Operating Temperature | 0 °C to 45 °C (+32 °F to +113 °F) |
| Operating Humidity | 10%–80% (RH), non-condensing |
| Operating Altitude | 5000 m (16404.20 ft) |
| Installation | Standard 19 inch rack CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN |
| Ordering Information | |
| Type | Model Description |
| 16-bay EVS | DHI-EVS5016S-R-V2 16-bay Embedded Video Storage The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product. |
| Panels | |
| 1 | 2 3 4 5 6 7 8 9 |
| 1 | 2 Power Input Ground |
| 3 | 4 RS-232 Port Operation Indicator Light |
| 5 | 6 eSATA Port Network Ports |
| 7 | 8 HDMI Port USB Ports |
| 9 | 10 VGA Port Power Switches |
