Convertitore seriale per centrale AirShield ARC3800H, 1 porta RS232 (input) e 1 porta RS485 (output), alimentazione da porta RS232 della centrale
Datasheet
Disegni
| Port | |
| RS-232 | 1 × RS-232 input port |
| RS-485 | 1 × RS-485 output port |
| Function | |
| Indicator Light | 1 power indicator |
| General | |
| Power Supply | Powered by the RS-232 port of Hub 2 |
| Operating Temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 10%–90% (RH) |
| Product Dimensions | 50 mm × 12.7 mm × 7.2 mm (1.97" × 0.50" × 0.28") |
| Net Weight | 5.21 g (0.01 lb) |
| Gross Weight | 50 g (0.11 lb) |
| Certifications | |
| Storage Temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Humidity | 10%–90% (RH) 106 mm × 90 mm × 45 mm (4.17" × 3.54" × 1.77") (L × W × H, 1 in inner carton) |
| Packaging Dimensions | 339 mm × 291 mm × 261 mm (13.35" × 11.46" × 10.28") (L × W × H, carton) |
