Struttura portante per 2 pannelli solari PFM371-M275
| General | |
| Installation | Pole mount |
| Material | Q235 |
| Color | Sliver Gray |
| Pole Diameter | 150 mm–220 mm |
| Adjustable Inclination Angle | 10°; 20°; 30°; 40°; 50° |
| Number of supported solar | 2 pcs × 275 W solar panels |
| Net Weight | 38 kg (83.78 lb) |
| Gross Weight | 40 kg (88.18 lb) 1730.7 mm × 1810.0 mm × 909.2 mm (68.14" × |
| Product Dimensions | 71.26" × 35.80") 1930 mm × 290 mm × 165 mm (75.98" × 71.26" × |
| Packaging Dimensions | 6.49") |
| Operating Temperature | –40 °C to +85 °C (–40 °F to 185 °F) |
| Operating Humidity | < 95% (RH) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to 140 °F) |
| Storage Humidity | < 95% (RH) |
| Ordering Information | |
| Type | Model Description |
| Solar Series | DH-PFM376-G 275W Solar Mount |
