Cavo di rete U/UTP CAT6 viola in matassa da 305 m, conduttori in rame puro privo di ossigeno (OFC), guaina esterna LSZH (bassa emissione di fumi, zero alogeni), classe di reazione al fuoco CPR Dca (EN 50575), prove EN 50399, EN 60332-1-2, EN 61034-2 ed EN 60754-2, dati e alimentazione PoE su un unico cavo, impedenza 100 Ω ±15 Ω, NEXT ≥39.3 dB/100 m a 250 MHz, attenuazione max 34.8 dB/100 m a 250 MHz, return loss ≥17.3 dB/100 m, raggio di curvatura >8 volte il diametro, temperatura di esercizio -20~+60 °C, peso netto 11 kg
| Transmission | |
| Characteristic Impedance | 100 Ω ± 15 Ω |
| Near-end Crosstalk | ≥39.30 dB/100 m@250 MHz |
| Max. Attenuation | 34.8 dB/100 m@250 MHz |
| Return Loss | ≥17.3 dB/100 m@250 MHz |
| Mechanical | |
| Tensile Strength | Sheath≥10 MPa, insulation≥16 Mpa |
| Elongation at Break | Sheath≥125%, insulation≥300% |
| Installation Bending Radius | >8 times of outer cable diameter |
| Conductor Elongation at | ≥10% |
| Environmental | |
| Shrinkage of Insulation | ≤5% |
| Color Migration Resistance | No migration |
| Elongation at Break after | ≥8 MPa, ≥100% |
| Low Temperature Bending | No cracking after the test |
| Heat Shock Test | No cracking after the test |
| Operating Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Installation Temperature | 0 °C to +50 °C (+32 °F to +122 °F) |
| Storage Temperature | –10 °C to +40 °C (+14 °F to +104 °F) |
| Storage Humidity | <60% (RH) |
| Security | |
| Vertical Flame Test | EN 50399; EN 60332-1-2; EN 61034-2; EN 60754-2 |
| Packaging | |
| Cable Length | 305.0 m± 2 m (1,000.66 ft ± 6.56 ft) |
| Packaging Method | 305 m/box 406 mm × 404 mm × 216 mm (15.98" × 15.91" × 8.50") |
| Packaging Dimensions | (L × W × H) |
| Transport Package | 455 mm × 435 mm × 436 mm (17.91" × 17.13" × 17.17") (L × W × H) |
| Net Weight | 11.00 kg ± 0.70 kg (24.25 lb ± 1.54 lb) |
| Gross Weight | 12.00 kg ± 0.70 kg (26.46 lb ± 1.54 lb) |
| Flame-Retardant Standard | |
| Compliance Standard | EN50575 |
| Ordering Information | |
| Type | Model Description 305m U/UTP CAT6 Network |
| Network Cable | DH-PFM923I-6UN-CD Cable (White, LSZH,CPR Dca) |
| /n | Pictures in the document are for reference only, and the actual product shall prevail. |
